MOON 860A v2 Dual Mono Reference Two-Channel Power Amplifier


MOON 860A v2 Dual Mono Reference Two-Channel Power Amplifier

Transparency and soundstage are exceptional, despite this amplifier’s high power rating. Ultimately, the MOON 860A v2 Power Amplifier will mate seamlessly with any loudspeaker allowing it to reach its full sonic potential, regardless of its load.
Product Colour
- Optional
- Optional
- Optional

exceptional transparency

The MOON 860A v2 Power Amplifier is a balanced differential dual-mono Power Amplifier that provides both exceptional transparency and a remarkable musical soundstage.

a true evolution

A true evolution on earlier designs, and incorporates trickle-down technologies from the massive 888 Power Amplifier.

MOON 860A in black

225W per channel

450W at 4Ω and 750W in monaral mode

product features

  • Monaural operation via rear-panel switch.
  • DC-coupled design with DC-servo control for greatest transparency.
  • Switchable AC-coupling for best match with a variety of preamplifiers.
  • Output stable into any load impedance.
  • Class A power output up to 5 watts.
  • Very high damping factor for superior musical dynamics, speaker control and refined harmonic accuracy and timbre.

in the box

  • power amplifier
  • AC power cable
  • Owner's manual
  • Output Power at 8Ω: 225 W per channel
  • Output Power at 4Ω: 450 W per channel
  • Output Power - Monaural mode at 8Ω: 750 W
  • Input Sensitivity: 1.2V
  • Input Impedance: 47,500Ω
  • Gain: 31dB
  • Signal-to-noise Ratio: 110dB @ full power
  • Frequency response (full range): 10Hz - 100kHz +0/-3.0dB
  • Crosstalk @ 1kHz: -110dB
  • THD (20Hz - 20kHz @ 1 W): 0.005%
  • THD (20Hz - 20kHz @ 200 W): 0.03%
  • Intermodulation distortion: 0.006%
  • Power Supply Capacitance: 240 000 uF
  • Shipping weight: 90 lb / 40 kg
  • Dimensions in inches: Width 18.75", Height 7.5", Depth 17.5"
  • Dimensions in cm: Width 47.6cm, Height 19.2cm, Depth 44.5cm
