Vertere Magneto Dual Moving Cartridge

Vertere

Vertere Magneto Dual Moving Cartridge

Price
£275.00
Vertere Magneto Dual Moving Cartridge

Vertere Magneto Dual Moving Magnet Phono Cartridge is designed and manufactured to exacting standards to provide an unparalleled musical experience in its class.

The Dual Magnet design replicates the structure of the cutter head.

A ‘V’ form two magnet design mimics the Left & Right channel sides of the record groove. This feature, with the permalloy centre shield plate, provides a higher frequency response with electrical crosstalk typically better than 40dB.

The Magneto utilises a finely finished Elliptical stylus to ensure outstanding tracking ability and super quiet tracing of the record groove. Use of laminated Para-toroidal coils with ‘V’ geometry of the magnets also gives rise to higher efficiency in generating the output signal.

The Magneto is an absolutely gem of a cartridge for any starter record playing system.

It is factory fitted to the DG-1 'Plug & Play' Dynamic Groove record player package to provide you with an unparalleled musical performance.

Features

  • Replaceable Stylus
  • Integrated Stylus Guard
  • Stainless Steel Fixing Bolts, Washer & Hex Thumb Nuts
  • Easy Alignment Assist Marking
Specifications
  • Frequency Response: 20 - 23,000Hz
  • Channel Separation: 27dB (1kHz)
  • Output Channel Balance: 1.5dB (1kHz)
  • Output Voltage: 4.0mV (1kHz, 5cm/sec.)
  • Vertical Tracking Angle: 23˚
  • Vertical Tracking Force Range: 1.8 – 2.2g (2.0g standard)
  • Stylus Shape: Elliptical Bonded
  • Stylus Size: 0.3 x 0.7 mil
  • Stylus Construction: Bonded Round Shank
  • Cantilever: Aluminium Tube
  • Coil Resistance: 800Ω (DC)
  • Static Compliance: 35 x 10-6 cm/dyne
  • Dynamic Compliance: 8 x 10-6 cm/dyne (100Hz)
  • Recommended Load Impedance: 47,000Ω
  • Recommended Load Capacitance: 100 – 200pF
  • Weight: 6.4g
  • Dimensions: 17.3 (H) x 17.0 (W) x 28.2 (L) mm
