Ultrafide DIAS-U8 Ultra Premium Power Amplifier
Price
£27,499.00
Product Condition
New
A masterpiece of sonic engineering
Harness the power of the gods with Ultrafide's new statement piece, DIAS-U8. Seamlessly blending classic and modern design, it's an amplifier that delivers pure, superior Class AB power with exceptional precision across two independent channels. Housed in a beautiful chassis with the total weight at a whopping 50kg.
Features
- A massive 2kW of pure class AB power, incorporating our unique TC Drive (TCD) technology
- Dual Mono – Separate channel HT and separate low power auxiliary rails ensures TOTAL channel independence
- 12 premium output devices per channel incorporating TLB technology
- Equal current sharing, therefore no bias affected audible changes
- True fully balanced design – XLR inputs and passive link outs
- Large 1000VA custom designed toroidal transformer linear PSU
- Special care and attention to ground paths to totally eliminate any ground induced noise
- Only 2 capacitors (1 per side) between input/output signal – DC coupling elsewhere
Specifications
- A massive 2kW of pure class AB power, across 2 totally independent channels
- Housed in a beautiful chassis with the total weight at 50Kg
- In-House class AB design, incorporating our unique TC Drive (TCD) technology
- 12 premium output devices per channel incorporating TLB technology (equal current sharing & therefore no bias affected audible changes)
- Dual Mono - Separate channel HT and separate low power auxiliary rails ensures TOTAL channel independence
- True fully balanced design - XLR inputs and passive link outs
- No peak current limiting therefore no sonic colouration
- Large 1000VA custom designed toroidal transformer linear PSU
- Special care and attention to ground paths to totally eliminate any ground induced noise
- Only 2 capacitors (1 per side) between input/output signal - DC coupling elsewhere
- Frequency Response: 5Hz - 20Khz +/- 0.5dB
- Noise: -73dBu (Un-Weighted 22-22KHz)
- Dynamic Range: 110dB (Un-Weighted 22-22kHz)
- Distortion (4R): 0.008% at 300W | 0.05% at 500W
- Rise/Fall Time: 5uS
- Premium Furutech C19 IEC mains inlet
- Our own in-house custom designed heatsinking. No "off the shelf" designs, common in this market. (Dedicated design ensures that cooling is totally optimised, whilst also looking stylish!)
